Hex Bolt

General Information

Material:

  • Carbon Steel and Alloy Steel
  • Stainless Steel

Property Class:

  • 6.8, 8.8 (Carbon Steel)
  • A2-70, A4-80 (Stainless Steel)

Manufacturing Specification:

  • ASME B18.2.1
  • ISO 4017
  • DIN 933

Mechanical Properties:

  • Bolts, screws and studs with specified property classes – Coarse thread and fine pitch thread (ISO 898-1:2009)
  • Mechanical properties of corrosion-resistant stainless steel fasteners – Part 1: Bolts, screws and studs (ISO 3506- 1:2009) (Stainless Steel)

Dimensional Specification

  • DIN 933, ISO 4017 for full threaded
  • DIN 931 for full semi-threaded

Coating

  • Electro galvanisation acc. to ASTM B633/ ASTM F 1941, EN ISO 4042
  • Hot Dipped Galvanized acc. to ASTM A153 / A123, EN ISO 1461, EN ISO 10684

Technical Specifications

AA BBB CCC DDD E F Code Description
ZCD 08 25 P ZCD0825P M8*25 Hex Bolt 6.8 DIN933
ZCC 16 70 P ZCC1670P M16*70 Hex Bolt 8.8 DIN933
99 ZCC 24 300 P 99ZCC24300P M24*300 Hex Bolt 8.8 DIN933
99 ZCCP 24 140 P 99ZCCP24140P M24x140 A4 Stainless Steel Hex Bolt DIN933
ZCD 10 40 H P ZCD1040HP M10*40 Hex Bolt 6.8 DIN933 – HDG
ZCP 16 100 P ZCP16100P M16x100 A2 Stainless Steel Hex Bolt DIN933
ZCD 20 120 P ZCD20120P M20*120 Hex Bolt 6.8 DIN931
