General Information
Technical Specifications
| INKA Code | Nominal Size | Pipe O.D | Working Pressure | Dimensions (L) | Weight per pcs | |
|---|---|---|---|---|---|---|
| Red | Galvanized | inch | inch | psi | mm | lbs |
| CTJXD0042034 | CTJXD0042034H | 1¼*1 | 1 21/32 x 1 5/16 | 300 | 2 17/32 | 1 |
| CTJXD0048034 | CTJXD0048034H | 1½*1 | 1 29/32 x 1 5/16 | 300 | 2 17/32 | 1 |
| CTJXD0048042 | CTJXD0048042H | 1½*1¼ | 1 29/32 x 1 21/32 | 300 | 2 17/32 | 1 |
| CTJXD0060021 | CTJXD0060021H | 2*½ | 2 3/8 x 27/32 | 300 | 2 17/32 | 1 |
| CTJXD0060027 | CTJXD0060027H | 2*¾ | 2 3/8 x 1 1/16 | 300 | 2 17/32 | 1 |
| CTJXD0060034 | CTJXD0060034H | 2*1 | 2 3/8 x 1 5/16 | 300 | 2 17/32 | 1 |
| CTJXD0060042 | CTJXD0060042H | 2*1¼ | 2 3/8 x 1 21/32 | 300 | 2 17/32 | 1 |
| CTJXD0060048 | CTJXD0060048H | 2*1½ | 2 3/8 x 1 29/32 | 300 | 2 17/32 | 1 |
| CTJXD0076021 | CTJXD0076021H | 2½*½ | 3 x 27/32 | 300 | 2 17/32 | 1 |
| CTJXD0076027 | CTJXD0076027H | 2½*¾ | 3 x 1 1/16 | 300 | 2 17/32 | 1 |
| CTJXD0076034 | CTJXD0076034H | 2½*1 | 3 x 1 5/16 | 300 | 2 17/32 | 1 |
| CTJXD0076042 | CTJXD0076042H | 2½*1¼ | 3 x 1 21/32 | 300 | 2 17/32 | 1 |
| CTJXD0076048 | CTJXD0076048H | 2½*1½ | 3 x 1 29/32 | 300 | 2 17/32 | 1 |
| CTJXD0076060 | CTJXD0076060H | 2½*2 | 3 x 2 3/8 | 300 | 2 17/32 | 1 |
| CTJXD0089021 | CTJXD0089021H | 3*½ | 3 1/2 x 27/32 | 300 | 2 17/32 | 1 |
| CTJXD0089027 | CTJXD0089027H | 3*¾ | 3 1/2 x 1 1/16 | 300 | 2 17/32 | 1 |
| CTJXD0089034 | CTJXD0089034H | 3*1 | 3 1/2 x 1 5/16 | 300 | 2 17/32 | 1 |
| CTJXD0089042 | CTJXD0089042H | 3*1¼ | 3 1/2 x 1 21/32 | 300 | 2 17/32 | 1 |
| CTJXD0089048 | CTJXD0089048H | 3*1½ | 3 1/2 x 1 29/32 | 300 | 2 17/32 | 1 |
| CTJXD0089060 | CTJXD0089060H | 3*2 | 3 1/2 x 2 3/8 | 300 | 2 17/32 | 1 |
| CTJXD0089076 | CTJXD0089076H | 3*2½ | 3 1/2 x 3 | 300 | 2 17/32 | 2 |
| CTJXD0114021 | CTJXD0114021H | 4*½ | 4 1/2 x 27/32 | 300 | 3 | 2 |
| CTJXD0114027 | CTJXD0114027H | 4*¾ | 4 1/2 x 1 1/16 | 300 | 3 | 2 |
| CTJXD0114034 | CTJXD0114034H | 4*1 | 4 1/2 x 1 5/16 | 300 | 3 | 2 |
| CTJXD0114042 | CTJXD0114042H | 4*1¼ | 4 1/2 x 1 21/32 | 300 | 3 | 2 |
| CTJXD0114048 | CTJXD0114048H | 4*1½ | 4 1/2 x 1 29/32 | 300 | 3 | 2 |
| CTJXD0114060 | CTJXD0114060H | 4*2 | 4 1/2 x 2 3/8 | 300 | 3 | 2 |
| CTJXD0114076 | CTJXD0114076H | 4*2½ | 4 1/2 x 3 | 300 | 3 | 2 |
| CTJXD0114089 | CTJXD0114089H | 4*3 | 4 1/2 x 3 1/2 | 300 | 3 | 2 |
| CTJXD0140060 | CTJXD0140060H | 5*2 | 5 1/2 x 2 3/8 | 300 | 3 1/2 | 2 |
| CTJXD0140076 | CTJXD0140076H | 5*2½ | 5 1/2 x 3 | 300 | 3 1/2 | 2 |
| CTJXD0140089 | CTJXD0140089H | 5*3 | 5 1/2 x 3 1/2 | 300 | 3 1/2 | 2 |
| CTJXD0140114 | CTJXD0140114H | 5*4 | 5 1/2 x 4 1/2 | 300 | 3 1/2 | 2 |
| CTJXD0165034 | CTJXD0165034H | 6*1 | 6 1/2 x 1 5/16 | 300 | 4 1/32 | 3 |
| CTJXD0165042 | CTJXD0165042H | 6*1¼ | 6 1/2 x 1 21/32 | 300 | 4 1/32 | 3 |
| CTJXD0165048 | CTJXD0165048H | 6*1½ | 6 1/2 x 1 29/32 | 300 | 4 1/32 | 3 |
| CTJXD0165060 | CTJXD0165060H | 6*2 | 6 1/2 x 2 3/8 | 300 | 4 1/32 | 3 |
| CTJXD0165076 | CTJXD0165076H | 6*2½ | 6 1/2 x 3 | 300 | 4 1/32 | 3 |
| CTJXD0165089 | CTJXD0165089H | 6*3 | 6 1/2 x 3 1/2 | 300 | 4 1/32 | 3 |
| CTJXD0165114 | CTJXD0165114H | 6*4 | 6 1/2 x 4 1/2 | 300 | 4 1/32 | 3 |
| CTJXD0219060 | CTJXD0219060H | 8*2 | 8 5/8 x 2 3/8 | 300 | 5 | 5 |
| CTJXD0219076 | CTJXD0219076H | 8*2½ | 8 5/8 x 3 | 300 | 5 | 5 |
| CTJXD0219089 | CTJXD0219089H | 8*3 | 8 5/8 x 3 1/2 | 300 | 5 | 5 |
| CTJXD0219114 | CTJXD0219114H | 8*4 | 8 5/8 x 4 1/2 | 300 | 5 | 5 |
